Description
Terminal Box with terminal block
Description
Terminal box Material: PA, Polymide66, 94-2 grade. Brass, screw is iron plated zinc.
Inflaming retarding, Working Temperature: 30°C ~ 110°C
Voltage: 250-450V
Color: according sample picture or customized.
| Item No. | Spec. | Rated Current(A) | Rated Voltage(V) | L1 | L2 | H | W | Max. Section | Hole Qty. |
| W×H(mm) | mm | ||||||||
| 207 | 6.5×12 | 125A | 500V | 67 | 48 | 50 | 45 | 35mm² | 2×7 |
| 211 | 6.5×12 | 125A | 500V | 100 | 86 | 50 | 45 | 35mm² | 2×11 |
| 215 | 6.5×12 | 125A | 500V | 134 | 118 | 50 | 45 | 35mm² | 2×15 |
| 407 | 6.5×12 | 125A | 500V | 67 | 48 | 50 | 90 | 35mm² | 4×7 |
| 411 | 6.5×12 | 125A | 500V | 100 | 86 | 50 | 90 | 35mm² | 4×11 |
| 415 | 6.5×12 | 125A | 500V | 134 | 118 | 50 | 90 | 35mm² | 4×15 |
| 413 | 8×17 | 160A | 500V | 180 | 168 | 73 | 138 | 50mm² | 4×13 |
