SINGLE ANCHOR THIMBLEYE ROD
Description
Produced in Steel Q235, hot dip galvanized according to ASTM A-153, BS729, ISO1461.
Furnished with 1 square nut.
| Type | Dimensions in inches and millimeters | |||
| A | B | C | D | |
| SATR01 | 60″(1524) | 4″(100) | 1 1/2″(38) | 5/8″(16) |
| SATR02 | 72″(1828) | 4″(100) | 1 1/2″(38) | 5/8″(16) |
| SATR03 | 84″(2133) | 4″(100) | 1 1/2″(38) | 5/8″(16) |
| SATR04 | 96″(2438) | 4″(100) | 1 1/2″(38) | 5/8″(16) |
| SATR05 | 72″(1828) | 4″(100) | 1 1/2″(38) | 3/4″(20) |
| SATR06 | 84″(2133) | 4″(100) | 1 1/2″(38) | 3/4″(20) |
| SATR07 | 96″(2438) | 4″(100) | 1 1/2″(38) | 3/4″(20) |
| SATR08 | 108″(2743) | 4″(100) | 1 1/2″(38) | 3/4″(20) |
| SATR09 | 120″(3048) | 4″(100) | 1 1/2″(38) | 3/4″(20) |
