Description
Copper Battery Lugs
Copper battery lugs are widely used in solar system, household appliances, automobiles, electrical industry, mechanical equipment, distribution box, battery , inverters etc. which are mainly used in electrical connection. They have the advantages of good conductivity, corrosion resistance and oxidation resistance.
The copper battery lugs is made from electrolytic copper construction that provides excellent conductivity. The copper lug is copper to resist corrosion from salt and moisture.
Copper Battery Lugs Type
Copper lug AWG type
| ITEM NO. | Dimension(mm) | |||||
|---|---|---|---|---|---|---|
| Φd2 | B | L | ΦD | Φd | E | |
| AWG 8#10 | 5.1 | 11.8 | 33.3 | 7.1 | 4.8 | 13 |
| AWG 8*1/4 | 6.8 | 11.8 | 33.3 | |||
| AWG 8*5/16 | 8.3 | 11.8 | 33.3 | |||
| AWG 8*3/8 | 10.4 | 14.5 | 33.3 | |||
| AWG 8*1/2 | 13.1 | 17 | 33.3 | |||
| AWG 6#10 | 5.1 | 11.8 | 37.3 | 8.1 | 5.9 | 15 |
| AWG 6*1/4 | 6.8 | 13.7 | 37.3 | |||
| AWG 6*5/16 | 8.3 | 13.7 | 37.3 | |||
| AWG 6*3/8 | 10.4 | 13.7 | 37.3 | |||
| AWG 6*1/2 | 13.1 | 17 | 37.3 | |||
| AWG 4*1/4 | 6.8 | 13.8 | 38.9 | 9.5 | 7.3 | 15.5 |
| AWG 4*5/16 | 8.3 | 13.8 | 38.9 | |||
| AWG 4*3/8 | 10.4 | 14.5 | 38.9 | |||
| AWG 4*1/2 | 13.1 | 17 | 38.9 | 15 | ||
| AWG 2*1/4 | 6.8 | 16.5 | 41.1 | 11.1 | 8.5 | 16 |
| AWG 2*5/16 | 8.3 | 16.5 | 41.1 | |||
| AWG 2*3/8 | 10.4 | 16.5 | 41.1 | |||
| AWG 2*1/2 | 13.1 | 17 | 41.1 | 15.3 | ||
| AWG 1*1/4 | 6.8 | 16.4 | 43.6 | 11.7 | 9.1 | 16 |
| AWG 1*5/16 | 8.3 | 16.4 | 43.6 | |||
| AWG 1*3/8 | 10.4 | 17.1 | 43.6 | |||
| AWG 1*1/2 | 13.1 | 19.1 | 43.6 | |||
| AWG 1/0*1/4 | 6.8 | 18.4 | 46.8 | 13 | 10.4 | 19 |
| AWG 1/0*5/16 | 8.3 | 18.4 | 46.8 | |||
| AWG 1/0*3/8 | 10.4 | 18.4 | 46.8 | |||
| AWG 1/0*1/2 | 13.1 | 21 | 46.8 | |||
| AWG 2/0*1/4 | 6.8 | 21 | 52.4 | 14.2 | 11.7 | 22 |
| AWG 2/0*5/16 | 8.3 | 21 | 52.4 | |||
| AWG 2/0*3/8 | 10.4 | 21 | 52.4 | |||
| AWG 2/0*1/2 | 13.1 | 21 | 52.4 | 21 | ||
| AWG 3/0*5/16 | 8.3 | 23.1 | 55.9 | 15.7 | 13 | 22.5 |
| AWG 3/0*3/8 | 10.4 | 23.1 | 55.9 | |||
| AWG 3/0*1/2 | 13.1 | 23.1 | 55.9 | |||
| AWG 4/0*5/16 | 8.3 | 25.8 | 60.5 | 17.2 | 14.2 | 24 |
| AWG 4/0*3/8 | 10.4 | 25.8 | 60.5 | |||
| AWG 4/0*1/2 | 13.1 | 25.8 | 60.5 | |||
Copper Battery Lugs DT Type
| Model | φ | D(mm) | d(mm) | L(mm) | L1(mm) | B(mm) |
|---|---|---|---|---|---|---|
| DT-10 | φ8.5 | 9 | 5.3 | 62 | 28 | 16 |
| DT-16 | φ8.5 | 10 | 6.5 | 68 | 30 | 16 |
| DT-25 | φ8.5 | 11 | 7 | 70 | 33 | 18 |
| DT-35 | φ10.5 | 12 | 8.5 | 80 | 36 | 20.5 |
| DT-50 | φ10.5 | 14 | 10 | 85 | 38 | 23 |
| DT-70 | φ12.5 | 16 | 11.5 | 95 | 43 | 26 |
| DT-95 | φ12.5 | 18 | 13.5 | 104 | 46 | 28 |
| DT-120 | φ14.5 | 20 | 15 | 112 | 49 | 30 |
| DT-150 | φ14.5 | 22 | 16.5 | 120 | 51 | 34 |
| DT-185 | φ16.5 | 25 | 18.5 | 125 | 55 | 37 |
| DT-240 | φ16.5 | 27 | 21 | 136 | 60 | 40 |
| DT-300 | φ21 | 31 | 23.5 | 155 | 66 | 50 |
| DT-400 | φ21 | 34 | 26.5 | 170 | 75 | 50 |
| DT-500 | φ21 | 38 | 29 | 190 | 75 | 60 |
| DT-630 | φ21 | 45 | 35 | 220 | 85 | 80 |
| DT-800 | φ21 | 50 | 38 | 260 | 85 | 100 |
Copper Lugs Ring Type
| Model | φ | D(mm) | d(mm) | A(mm) | L3(mm) | L(mm) | L1(mm) |
|---|---|---|---|---|---|---|---|
| DTG-16 | φ8.2 | 9 | 6 | 128 | 25 | 80 | 29 |
| DTG-25 | φ8.2 | 10 | 7 | 14.1 | 25 | 85 | 32 |
| DTG-35 | φ8.2 | 11 | 8 | 15.4 | 25 | 90 | 33 |
| DTG-50 | φ8.2 | 13 | 10 | 18.8 | 25 | 99 | 37 |
| DTG-70 | φ12.5 | 16 | 12 | 22.5 | 35 | 120 | 43 |
| DTG-95 | φ12.5 | 18 | 14 | 26 | 35 | 125 | 45 |
| DTG-120 | φ14.5 | 20 | 15.2 | 29 | 35 | 134 | 50 |
| DTG-150 | φ14.5 | 22 | 17 | 31.7 | 35 | 139 | 52 |
| DTG-185 | φ14.5 | 24 | 19 | 34.4 | 35 | 150 | 60 |
| DTG-240 | φ16.5 | 26 | 21 | 37.7 | 45 | 160 | 70 |
| DTG-300 | φ16.5 | 30 | 24 | 43.4 | 45 | 164 | 75 |
| DTG-400 | φ16.5 | 4 | 27 | 49 | 60 | 180 | 80 |
| DTG-500 | φ20.5 | 38 | 30 | 55.5 | 60 | 225 | 90 |
| DTG-630 | φ20.5 | 45 | 35 | 64.7 | 60 | 235 | 105 |
Related product of Copper Battery Lugs
More Copper Lugs type,please click here.
Catalogue download
If you want to know the Copper Battery Lugs price,please feel free contact us.
